MaxiSys Elite Main Menu

The MaxiSys Elite application allows you to establish a data link to the electronic control system of the test vehicle via the VCI device for vehicle diagnosis, service or programming. You can operate functional tests, retrieve vehicle diagnostic information such as trouble codes, event codes and live data, and perform ECU reprogramming, for various vehicle control systems, such as engine, transmission, ABS and more.

1.Diagnosis 一 a comprehensive section which includes all available functions: reading, clearing, saving and printing diagnostic information, as well as performing active tests and special functions
2.Service 一 a separate section designed to perform vehicle scheduled service and maintenance, such as to reset the service lights and perform calibration for various systems
3.Programming/Coding 一 a separate section designed for quick access to ECU reprogramming operations. After a section is selected and the tablet establishes communication with the vehicle via the VCI device, the corresponding function menu or selection menu displays.

Diagnosis
There are two options available when accessing the Diagnosis section:
1.Auto Scan 一 starts auto scanning for all the available systems on the vehicle
2.Control Units 一 displays a selection menu of all available control units of the test vehicle

Auto Scan

29-1

The Auto Scan function performs a comprehensive scanning over all the systems on the vehicle’s ECU in order to locate fault systems and retrieve DTCs. The sample operation interface of Auto Scan displays as below:

1.Navigation Bar
2.Main Section
3.Functional Buttons

Navigation Bar

1.List Tab — displays the scanned data in list format
2.Tree Tab — display the scanned data in system distribution diagram format
3.Progress Bar — indicates the test progress

Main Section

1.List Tab
Column 1 – displays the system numbers
Column 2 – displays the scanned systems
Column 3 – displays the diagnostic marks indicating different conditions of the test result:

-!-: Indicates that the scanned system may not support the code reading function, or there is a communication error between the tester and the control system.
-?-: Indicates that the vehicle control system has been detected, but the tester cannot accurately locate it.
Fault | #: Indicates there is/are detected fault code(s) present; “#” indicates the number of the detected faults.
Pass | No Fault: Indicates the system has passed the scanning process and no fault has been detected.

2.Tree Tab
The tree tab screen displays a system distribution diagram of the vehicle control modules. The scanned system which has passed scanning with no fault is shown in blue font; whereas the scanned system that has been detected with fault present is shown in red font.

17.Tab the @ button to the right of the system item, on which you want to perform further diagnosis and other test activities. A Function Menu screen shall then display.

29-2

Functional Buttons
The table below provides a brief description of the Functional Buttons’operations in Auto Scan:

29-3

Control Units
This option allows you to manually locate a required control system for testing through a series of choices. You simply follow the menu driven procedure, and make proper selection each time; the program will guide you to the diagnostic function menu after a few choices you’ve made.

29-4

The Function Menu options vary slightly by different vehicles. The function menu may include:
1.ECU Information 一 provides the retrieved ECU information in detail. Selecting opens an information screen.
2.Read Codes 一 displays detailed information of DTC records retrieved from the vehicle control module.
3.Erase Codes 一 erases DTC records and other data from the ECM.
4.Live Data — retrieves and displays live data and parameters from the vehicle’s ECU.
5.Active Test 一 provides specific subsystem and component tests. This Auto Diagnostic tool may appear as Actuators, Actuator Test, or Function Tests, etc., and the tests options vary depending on the manufacturer and model.
6.Special Functions 一 provides component adaptation or variant coding functions for custom configurations, and also allows you to reprogram adaptive values for certain components after making repairs. Depending on the test vehicle, this selection may sometimes appear as Control Unit Adaptations, Variant Coding, Configuration or something similar.

NOTE: With the diagnostic toolbar on top of the screen throughout the whole diagnostic procedures, you are allowed to make various controls of the diagnostic information at any time, such as printing and saving the displayed data, get help information, or perform data logging, etc.

To perform a diagnostic function
1.Establish communication with the test vehicle via the VCI device.
2.Identify the test vehicle by selecting from the menu options.
3.Select the Diagnosis section.
4.Locate the required system for testing by Auto Scan or through menu driven selections in Control Units.
5.Select the desired test from the Function Menu.

ECU Information

This function retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications. The Autel Scanner ECU Information screen displays as below:

29-5

Diagnostics  Toolbar  Buttons – for  detailed  descriptions  of the  operations  for  each button.

29-6
29-7 29-8

Main Section 一 the left column displays the item names; the right column shows the specifications or descriptions.
Functional Button 一 In this case, only a Back (or sometimes an ESC) button is available; tap it to exit after viewing.

Read Codes
This function retrieves and displays the DTCs from the system. The Read Codes screen varies for each vehicle some vehicles, freeze frame data can also be retrieved sample Read Codes screen displays as below:

29-9

Diagnostics Tool bar Buttons – see Table 4-2 Diagnostics Toolbar Buttons on page 33 for detailed descriptions of the operations for each button.

Main Section
* Code Column – displays the retrieved codes from the vehicle.
* Status Column – indicates the status of the retrieved codes.
* Description Column 一 detailed descriptions for the retrieved codes.
* Snowflake Icon – only displays when freeze frame data is available for viewing; Selecting displays a data screen, which looks very similar to the Read Codes interface, therefore same operation method may be applied.

Functional Button – in this case, only a Back (or sometimes an ESC) button is available; tap it to return to the previous screen or exit the function.

Erase Codes
After reading the retrieved codes from the vehicle and certain repairs have been carried out, you can decide to erase the codes from the vehicle using this function. Before performing this function, make sure the vehicle’s ignition key is in the ON (RUN) position with the engine off.

To erase codes
1.Tap Erase Codes from the Function Menu.
2.A warning message displays to inform you of data loss    when this function is applied.
1).Tap Yes to continue. A confirming screen displays when the operation is successfully done.
2).Tap No to exit.
3.Tap ESC on the confirming screen to exit Erase Codes.
4.Check the Read Codes function again to ensure the operation is successful.

A.Live Data
When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary from one vehicle    to another. The parameters display in the order that they    are transmitted by the ECM, so expect variation between vehicles.

Gesture scrolling allows you to quickly move through the data list. Simply touch the screen and drag your finger up or down to reposition the parameters being displayed if the data covers more than one screen. The figure below shows a typical Live Data screen:

29-10



B.Active Test
The Active Test function is used to access vehicle-specific subsystem and component tests. Available test vary by manufacturer, year, and model, and only the available tests display in the menu.
During an active test, the tester outputs commands to the ECU in order to drive the actuators. This test determines the integrity of the system or parts by reading the engine ECU data, or by monitoring the operation of the actuators, such as switching a solenoid, relay, or switch, between two operating states.
Selecting Active Test opens a menu of test options that varies by make and model. Selecting a menu option activates the test. Follow all screen instructions while performing tests. How and what information is presented on the screen varies according to the type of test being performed. Some toggle and variable control tests display Active Test Controls at the top of the screen with data stream information below, or vice versa.

29-11

The functional buttons at the lower right corner of the Active Test screen manipulate the test signals. The operational instructions are displayed on the main section of the test screen. Simply follow the on-screen instructions and make appropriate selections to complete the tests. Each time when an operation is successfully executed, message such as “Command Finished”, “Activation Successful”, or something similar displays. Tap the ESC functional button to exit the test when finished.

How To connect the MaxiSys display tablet with the VCI device via Ethernet

This section describes the general procedure to connect the tablet with the J2534 ECU programming device via Ethernet connection. To establish successful communication, you need to set up the network configuration on the display tablet.

1.If not already done, power up the Autel OBD2 MaxiSys display tablet.
2.Connect the MaxiSys Display Tablet to the J2534 ECU programming device with the accompanied Ethernet serial cable.
3.Select the VCI Managerapplication from the MaxiSys Job Menu.
4.Select the Wired Network.option on the Connection Mode list.The Ethernet Setting screen displays on the right section.
5.Select a connection type:
DHCP–obtains the LAN IP address automatically
Manual–allows you to enter IP address manually
6.If Manual is selected, you need to set the IP address on your own.
24-1
NOTE:If you are not sure about the specific IP address values, please contact your network administrator.

7.Tap Apply to set up the wired network connection.

When the wired network is successfully connected, the connection status is displayed as Connected, and the two status lights at the corners alongside the Ethernet Ports on the display tablet illuminate. The solid amber light indicates steady connection, and the flashing green light indicates active communication, between the units. The Autel MaxiSYS Elite navigation button at the bottom bar shall display a green tick icon after a few seconds, indicating the MaxiSys Elite diagnostic platform is ready to perform vehicle diagnosis.

MaxiSys Elite Main Cable

The VCI device can be powered through the Main Cable when connected to an 〇BD ll/EOBD compliant vehicle. The Main Cable of MaxiSys Elite connects the VCI device to the vehicle’s data link connector (DLC), through which the VCI device can transmit vehicle data to the Scanner MaxiSYS display tablet.

19-1

OBD I Adapters

The OBD I adapters are for Non – OBD II vehicles. The adapter used dependson the type of vehicle make being tested. The most common adapters are shown below.

19-2

Other Accessories

1.Standard 2.0 USB Cable
Connects the display tablet to the VCI unit.

19-3

2.Mini USB Cable
Connects the display tablet to the PC.

19-4

3.AC/DC External Power Adapter
Connects the display tablet to the  external DC power port for power supply.

19-5

4.Compact Disc (CD)
Includes the User Manual, Printing Services Program and Update Application, etc.

19-6

5.Ethernet Serial Cable
Connects the display tablet to the VCI unit.

19-7

6.Cigarette Lighter
Provides power to the display tablet or the Autel Scan Tool J2534 programming device through connection to the vehicle’s cigarette lighter receptacle, as some non – OBD II vehicles cannot provide power via the DLC connection.

19-8

7.Clipper Cable
Provides power to the display tablet or the J2534 programming device, through connection to the vehicle’s battery.

19-9

8.Lighter Fuse
A safety device for the cigarette lighter

19-10

9.Screwdriver
Unscrews the rear cover of the display tablet for easy replacement of the battery or the Diagnostic Scan Tool.

19-11

10.USB Ethernet Adapter
Connects the device to an Ethernet network

19-12

Excel Export of Order Details Tab Data of CAT ET

All Order Details data can be exported in one step to an Excel spreadsheet file

The data of CAT ET from each Order Details tab will be populated on a separate worksheet in one Excel spreadsheet file

Click on the Export Excel button on the Order Details page to export the Order Details data

Excel Export of Order Details Tab Data

14-1 14-2

Order Details –Revoked Licenses Tab Detail

14-3

Order Details – Editable Fields

-> Order Name
-> Purchase Order
-> Organization
-> Attention – Only editable if license is Assigned

Order Details Editable by Dealer Admin
14-4

Order Details Editable by Auto Scanner

14-5

Order Details Attention
* – Editable by Dealer Admin
* License must be Assigned

14-6
14-7
14-8

Licensing Expiration Schedule

Cat ET
–Dealer Cat ET license will run January – December each year
–Customer CAT ET license expires 365 days from the date the license ORDER is placed in the Dealer Software Licensing (DSL) system

SIS DVD and SIS Network
–Dealer  SIS DVD license will run January – December each year
–Customer SIS DVD license expires 365 days from the date the license ORDER is Placed in the Dealer Software Licensing (DSL) system

9-1 9-2

Managing Licenses
– Yearly Orders of Licenses
– Caterpillar created License Orders for each Dealer by Subscription Type for Dealer
– Caterpillar Renews DEALER SITE LICENSE Orders (JERD2129, RERA0004 & NEXG5043) in October and will renew yearly
– Each Dealer will need to Renew their CUSTOMER Orders by Subscription Type for Customer Usage (JERD2125, NEXG5007, NEXG5009, RERA0003, etc.) prior to the Order Expiration Dates

Managing Licenses
– Assigning a License
– Each order contains a specific number of licenses
– A license is UNASSIGNED until an authorized DSL user ASSIGNS the license by NAME to an individual user

9-3

9-4

New Software License Order

Yearly Order of the Number of Licenses Required
Customer Subscriptions automotive scan tool Cat ET and SIS DVD
Dealer Subscriptions Olympian EST Olympian Compass USB

New Software License Order ET Caterpillar

9-5

New Software License Order – Cat ET Customer

9-6
New Software License Order – Cat ET Customer

9-7 9-8

New Software License Order Receipt

9-9

Assign a License

9-10

9-11

Transferring a License of CAT ET

Transferring a License of  CAT ET
29-1

Important
If you are transferring your service tool license from another computer, you must have the Serial Number from the original license.

Instructions

To transfer your license, complete these two steps:

Step 1
Obtain the Serial Number from the original service tool program. If you do not know this number, select About Electronic Technician from the Help menu. The Serial Number will display in the message box. Write down the Serial Number.

Step 2
Install the Best Car Diagnostic Tool onto the new computer (the computer you are transferring your license to). With the Licensing dialog box displayed in front of you, call Caterpillar Media and Product Information Logistics. Refer to “Licensing Caterpillar Electronic Technician,”

How toinstall anduse Cummins INLINE 5 and Cummins INLINE 6?

1. How toinstall Cummins INLINE software ?

Free download Cummins Inline 7.6.2 (connect cnautotoo.com) and get how to install Cummins Inline software. to use with Cummins Inline 5 Cummins Inline 6 data link, DPA5 Dearborn, NEXIQ USB Link, XTruck USB Link for truck diagnosis.



THE MOST IMPORTANT- a working Cumminsinline crack or original
There are many links below to download Cummins inline for free; but usually the software may come with unknown security coz never be tested by professionals, or expire after use for several days. For sake of safety, you had better use a tested version.( Please contact us for technical assist , we will offer the correct software )

http://www.cnautotool.com/goods-364-Cummins+Inline+5+Insite+762+Diagnostic+Tool.html

http://www.cnautotool.com/goods-4980-Cummins+INLINE+6+Data+Link+Adapter+Cummins+Diagnostic+Tool.html



Cummins INLINE Software System Compatibility:
1.Windows 7 32-bit and 64-bit
2.Windows 8 32-bit and 64-bit
3.Windows 8.1 32-bit and 64-bit
4.Windows 10 32-bit and 64-bit



How to step by step install Cummins Inline 7.6.2:
1) Open the folder < Cummins InSite7.6.2 install>
2) open the autorun.exe
3) Here is Inline installation menu
4) go to manually install packages
5) install 7.6.2
6) go to upgrade Inline on the dvd menu
7) let update manager find the updates off the dvd
which will update it just below sp5
8)change dropdown un update manager to find updates off internet and let it completely update
I think 7.6.1 has been removed off their site and 7.6.2 needs it
9) disable your antivirus program
10) Open the folder Cummins Inline 7.x keygen (Cummins 7.x kg)
11) insert your PC-ID and get key for activation
12) .insert the activation key to run the software

How unlock the expired program CumminsInline:
Now you need to start to change the date on the computer,
set the date 1 January 2014 on your computer/notebook.
Then run the program INSITE. You will see a message about changing the date. Click OK.
Now you can see the PC-ID and Verificaton Code
for ex. see the picture:

Open the Cummins Date Unlock and set the same date 1 January 2014 and your PC-ID and Verification Code.
Clik the Make Passwords!
Now you have the unlock password code.

Cummins Inline 7.6.2review of operation systems:
I have had it work on win10 home too but it quit working. I reformatted my drive tried to install insight and it says something is interrupting install. I am trying it on win10 pro.

I installed 7.6.0 and it worked fine, I then copied my entire Intelect folder from another computer that is running XP withinsite 7.6.2 to a flash drive and from the flash drive I moved the intelect folder to the computer that I am using windows 8.1 on. It worked fine for me after unlocking and applying the SP5 patch. I did the same to a computer using windows 10 with no issues.

I install version 7.6 of inline in Windows 10 without any problem, the following maner before giving double click the setup, then you give right- click and select properties select compatibility compatibility mode to win xp sevice pack 2 and ready the program began to install only have patience

I’m running Ubuntu 15.10 with VirtualBox, and Win XP VM. INSITE works perfectly, and not one problem with the install. I have done it multiple times. Try running a VM with an older version of Windows. Just my two cents.

I have install all Inline, Jpro, DDDL, on win 8.1 then updated to win 10 all work fine on issue.

i got mine to work but had to set it as admin and run as windows 7.

2. How to useCummins INLINE?

Cummins inline training: How to program Volvo, Cummins, CAT ECM with Cummins inline heavy duty diagnostic software?



Tools required:
Software: Cummins inline Pro software
Hardware options: Cummins Inline 6 data link, Nexiq adapter or DPA5 truck scanner

Cumminsinlinecrack 8.1: 100% works good



Now, we’ll go to program ECM with Cumminsinline pro

1. Connect truck scanner to the car with the 9pin to OBD2 cable







2. Connect DPA5 orCummins INLINE or nexiqto the laptop with the USB cable

3. DPA5 orCummins INLINE or nexiqis communicating…



4. Run Cummins inline software

Select dual CAN



5. Connect to ECM

.

6. Fault codes



7. Work orders



7. Disconnect from ECM



8.Close Cummins inline software

Audi A3 MQB mileage correction via OBD by obdstar X300M

Audi A3 MQB mileage correction via OBD using OBDSTAR X300M succeed, it is easy to operate by following the instruction made by CnAutotool.com engineer.

Guide:

Audi A3 MQB Mileage Correction by OBDSTAR X300 DP PAD

The green one is the same as the orange X300 DP, the only difference is the outlook color.

Audi A3 old value 400KM

24-0

Here Audi A3 MQB key front and back.

24-01

24-02

Choose option “Vehicles”

24-04

Choose “Mileage adjustment”

24-03

Choose “Audi”, then “Audi V31.55”, then loading…Initializing…Authorizing…

24-05024-05

Select “A3”

24-06

Choose “MQB 2014.06 -”

Message : Only MQB dashboard of mainland and VDO are supported.

24-07
24-08

Switch ignition on.

24-09

Mileage adjustment

24-10

Confirm the current mileage value.

Please input the new value you would like to adjust.

Communicating… Loging system…

24-11
24-12

You will hear a ticking sound, then the dashboard lights up.

Writing data…

24-13

Audi A3 MQB mileage correction succeeds with OBDSTAR X300M OBDII.

24-14

MAN CAT T200 MAN Cats T200 Truck Diagnostic Tool

MAN Cats T200 man truck diagnostic tool is an external diagnosis system with the most extensive test depth for electrical systems in MAN commercial vehicles. Man T200 Man Heavy Duty Diagnostic Tool Dealer Level diagnosis system is ideally suited to use in a workshop as well as mobile usage.

MAN Diagnostic Tool MAN CATS T200 Truck Diagnostic Tool

Top 4 Reasons to Get Man Cat t200?:

1. Man Diagnostic Tools for Trucks Cat 2 T200 is special dealer level diagnostic too for MAN trucks.
2. Man T200 Cat II support both Diagnose and Offline programming.
3. Man-Cats T200 Man Heavy Duty Scanner is with one year warranty.
4. MAN CATS T200 Truck Diagnostic Tool support multi-languages:
German, English, French, Spanish, Italian, Dutch, Portuguese, Russian, Greek, Croatian, Turkish, Polish, Romanian

Notice: Man Cat II T200
software (V2.14) not support update.

19-1

19-2

19-3

Examples of Diagnosable Systems:

Electronic brake systems (EBS).
Electronically controlled air suspension (ECAS).
Engine regulation (EDC).
Retarder.
Gearbox.
Air-conditioning systems.
Central computer.
Instrumentation.
Door module.
Airbag.
And much more.

Possibilities of Use:

Simple testing of actuators.
Visualisation and assessment of current sensor signals.
Identification of control unit in assembled condition.
Depiction of all stored diagnosis entries.
Fast orientation on vehicle by means of integrated overview wiring diagrams.
HD-OBD scantool (Heavy Duty On Board Diagnosis), read-out and presentation of data relevant to exhaust gas.

19-4 19-5 19-6 19-7 19-8

Package Including:

1pc x  T200 Communication Interface
1pc x  OBD2 Main Cable
1pc x 12-pin Round Cable
1pc x OBD2 Adapter Cable
1pc x USB Cable

How to Select a Personal OBD 2 Reader

It may not be as easy as one may think when setting out to select personal OBD 2 reader for your car. This is because each car is unique and may need to be treated as such. However the whole how to process will be dependent on some areas which one needs to cover.

Though the OBD 2 readers may come in all shades of color and sizes, the right one is just within your reach if you only tried. Our guide is therefore focused at giving you a one on one account of how to go about selecting the right Auto code reader for your car.

14-1

The confidence you are bound to experience will definitely improve your car use experience. In addition, selecting the right OBD 2 reader is important in enabling you keep safe and sound while driving.

Learning this selection process alone has made many people escape from the numerous problems they would have encountered by getting an OBD 2 reader which does not fit their car needs.

Some of the areas to cover include;

1.Know the user language– because some of the OBD 2 is not multilingual in nature, using them may prove to be quite challenging and so may require the buyer to look carefully when selecting. Choose an OBD reader which conforms to your catchment language.

2.Know how the Car code reader of your car operates– for starters, you may need to know whether your car is compliant. Most modern cars are compliant with the possibility of accommodating different car readers.

In addition to that, ensure that the car has the required area where the OBD 2 device will be easily connected. This will be good for the sake of convenience and ease of use.

3.Get a wider network– in the selection process; do not be fixed at one item look for a reader which is capable of diversifying. The most important area is to ensure that the OBD 2 reader has the capacity to get the required data readings.

Most modern cars are compliant with the possibility of accommodating different car readers.

What would be nice to look at in this case is in the area of the codes. The reader should have the ability to get the manufacturer specific as well as generic codes for you. These need to be wide range in nature.

This network would be best if you sought it from the different sources which include reading of the user reviews and connecting with friends. Other areas where you may visit would be visiting the manufacturer sites directly.

In addition, selecting a reader with a wide range of capacities may just be what you are looking for. The best case would be a reader which can perform tasks of car code reading while attempting to assist with the repair process as well.

The wide coverage also needs to consider things like the coverage of the several user protocols which are known to be standard in nature. All the above information can be evident if you look at some of the features of your OBD 2 reader.

14-2

You need to know which of the devices suits your car

It would be nice if you just took your time to acquaint yourself with the latest trends on the diverse car engine protocols which are in use at any given moment in time. It will definitely save the buyer a lot of stress.

The features– though each of the Car Scanner come with its own features, what is important is that the reader needs to have some of the latest features just like you need to have your car updates.

In addition, the features need to be easy to read and use. For instance, the OBD 2 reader’s memory needs to be large enough to store data for the future if needed. In addition, the visual areas like the screen must be clear and eye friendly.

Check for relevance– most users buy the OBD 2 readers without knowing which of the areas it will be attending to. This act alone is enough to subject the reader to irrelevance. In some areas, the tool may be so efficient but working on the wrong problem.

Shop for the OBD 2 readers– the range of OBD 2 devices in the market alone is enough to give you an advantage when selecting the readers. You need to know which of the devices suits your car and whether it will be a standalone or the ones which rely on the car engine.

It would be nice if you went around and shopped for a reader which has the specifications fitting your car. What however may need to be taken into account is the universal nature of some of the OBD 2 readers.

Conclusion

Getting the how to information on the Mileage Correction is hard in the market. Most areas which concern the use of the readers are quite popular when compared. Reviews concern themselves mostly with areas to do with the functional strengths and weaknesses.

If you were seeking some relevant information, then you are surely in the right place. This resource therefore makes it among the relevant information you need to seek before settling for any OBD 2 reader purchase.
