BMW ICOM A2 emulator system red indicator flash

Before go deep into the topic today, let’s check the BMW ICOM ICOM A and ICOM B module indicator and meanings.

14-1 14-2

It is not different to see that if the Red LED indicator of either ICOM A or ICOM B emulator flashes, the Rheingold ISTA-D ISTA-P software will report error and fail to communicate with vehicle.

Problem& Symptom:

BMW ICOM A2+B+C diagnostic system A2 module red indicator blinking when connected to vehicle with LAN cable.

Solution:

2 solutions provided by experienced BMW ICOM diagnostic system experts:

DISCLAIMER: We are not responsible for the damage.

1)

1-rehot hot air gun this IC

2- Replace or change new one if necessary

3-The problem is the IC

14-3

2)

Fix the ICOM A2 from CnAutotool.com emulator firmware follow the PCB board displayed below:

The pulse generator to buy on auctions

14-4

white wire=the line to the WiFi antenna.

Others all marked in the PCB board

How to use BMW Rheingold ISTA

9-1

ISTA is a workshop system that contains BMW AG Data and Information. ISTA stands for Integrated Service Technical Application. Way back when, during the initial development of this tool, BMW diagnostic software (Diagnostics Information System), and as the programs evolved and due to the nature of the file naming conventions utilized by BMW, the workshop system became known as Rheingold in the enthusiast world. Rheingold in actuality is the folder that contains the main application and data. Rheingold became ISTA-D (D stands for Diagnostics) and BMW’s programming application (not discussed in this document) used the same nomenclature, ISTA except with a P (for programming) or ISTA-P.

BMW Rheingold 4.06.31 ISTA Functions List:

1. Module (ECU) errors reading and clearing

2. Gearbox (transmission) and engine adaptations erasing

3. Fuel injectors control, correction amount real time viewing, injector registering

4. Engine mountings testing

5. Mass air flow (MAF) testing and registering. Whole air system testing

6. EGR system control and testing

7.Turbocharger and related components control and testing

8. Diesel particulate filter regeneration (DPF)

9. Battery replacement

10. Oil change and service interval reset

11. Wiring diagrams, live data, repair instructions, technical documents etc

12. Programming, vehicle retrofit, mirror coding, FSC codes adding or updating etc

….

And many more other functions

System Requirements:

Windows 7 (32-bit or 64-bit)

Windows 8 or 8.1 (32-bit or 64-bit)

Windows 10 (32-bit or 64-bit)

Minimum system configuration is now hard coded into the program, although the standalone

versions have this check removed.

2.2Ghz CPU – 2 core minimum, core i5 or i7 recommended

4GB RAM, 8GB recommended

Minimum 20+GB HDD free space for ISTA+ Diagnostics with ONE language, and minimum

100GB for Programming Data.

This version has hardware check removed, however, future versions MAY not have this

feature. A faster system is required.

This version discusses included English Databases only. If more required, add to SQLiteDBs folder, which will need more space.

Interfaces and other requirements

E-S ERIES :

Interface = K+DCAN Cable or ICOM A1/ICOM A2/ICOM Next
EDIABAS = Low Level ECU Communication Software Server used by ISTA+

F/G/I/M INI /RR-S ERIES :

Interface = ENET Cable or ICOM

ICOM:

ICOM A: main interface
ICOM B: adapter for programming multimedia in E series
ICOM C: adapter for old BMW with round 20 pin diagnostic plug
ICOM D: adapter for motorcycles

BMW Rheingold ISTA User Manual PDF Download:
User manual 1:

1 Introduction

Explanation of the symbols used

Important security instructions

Chapter contents

Integrated Service Technical Application (ISTA)

ISTA operating modes

Data exchange with other systems

Distinguishing different makes

General operation of the ISTA workshop system

2 Overview and short introduction

Starting the ISTA Client

Checking the operations list

Selecting a vehicle

Selecting a diagnostic connection to the vehicle

Creating an operation

Finding out about operation details

Perform vehicle test

Display fault memory

Editing a test plan

Running a procedure

Terminating an operation

3. Menu structure

Start mask

Identification

Vehicle test.

Activities

Service plan

Operation
4. Appendix

Scope of functions for operator devices

Abbreviations

Glossary

Fault messages and fault rectification

Index
BMW Rheingold ISTA User manual 1 download

User manual 2:

1. BMW Rheigold ISTA Introduction

2. System Requirements

3. Interfaces and other erqurements

4. How To Install BMW Diagnsotic Tool Rheingold ISTA Software

5. Programming note

6.Interface configuration and verification with ISTA+

7. Diagnostics with ISTA+

2017A Version CAT Caterpillar ET Diagnostic Adapter III PLUS DELLd630 laptop (Real Caterpillar ET3 Adapter III)

2017A Version CAT Caterpillar ET Diagnostic Adapter III PLUS DELLd630 laptop (Real Caterpillar ET3 Adapter III)

we will install the software before ship, so you can get it work directly after you receive it.
2017A Cat ET software as Cat Caterpillar ET 2015A Software update version, 2017A Caterpillar Electronic Technician softwarer With CAT ET 3 Cat caterpillar adapter 3 support caterpillar diagnostic till 2017.

Cat et Caterpillar Electronic Technician Software 2017A V1.0:
Type of catalogue: Caterpillar Electronic Technician Diagnostic Software
Make: Caterpillar
Region: WorldWide all region
Inclusive languages: English, Chinese, Danish, French, German, Italian, Japanese, Portuguese, Russian, Spanish

Caterpillar ET Software 2017A Function:
This diagnostic app allows you to:
View active and logged diagnostics.
View events where irregularities occurred and were logged by the ECM.
View the status of a group of parameters (temperatures, pressures, etc.) simultaneously.
Record and log performance data.
Graph a group of status parameters.
View the current configuration of an ECM.
Change ECM configurations.
Perform diagnostic tests.
Perform calibrations.
Print reports and diagnostic results.
Please keep in mind that some ecm settings for example, speed limit requires factory password. The factory password generator is not included in this application
Package :
1.Used Dell D630 laptop
2.Real CAT et3 Comm Adapter III(it’s best quality cat et 3,not adapter 2,please check Communication port)
3.USB Cable (From device to your computer)
4.J1939/J1708 Cable (from device to your truck)

 Original Factory Caterpillar ET3 Adapter III Compare With OEM Caterpillar ET Diagnostic Adpater III
1. Original Factory Heavy Duty Vehicle Diagnostic CAT ET can use once pluged, no need install the USB drive, the software can automatic realize it for ET3 Adapter, and the machine can automatic weld the high quality Circuit board, quality will be more reliable.

2. The OEM Caterpillar ET Diagnostic Adapter III need use USB Drive to install, and need choose the COM Port, and  in the software ET also need choose ET2 then can be used.

The Details as follows:

OBDSTAR X300 DP X-300DP PAD Functions Updated

OBDSTAR X300 DP is the first tablet of OBDSTAR, which has reached a higher level inkey programming and diagnosis.

Full Configuration: Immobilizer+ odometer Adjustment+ EEPROM/PIC Adapter+ OBDII+ ABS+ TPS+ SRS Reset+ TPMS(Low Tire) Reset+ Steering Angle Reset+ CVT Learning/Value Reset+ EPB+ Oil/service Reset+ Battery Matching+ Full systems Diagnosis (Japanese and Korean Serials,more car models for diagnosis will be added in the future)

OBDSTAR X300 DP Update Announcement on July 31st

1. Odometer Reset:

Solve NEC 95320 MM dash board type odometer reset function defects

Solve NEC 24C64_VDO dash board type odometer reset function defects

Solve Sagitar (2007-2010) CDC24C32 dash board type odometer reset function defects

Solve NEC24C32 dash board type odometer reset defects

Solve W251, W164 odometer reset defects

Solve the following models odometer reset function

Crown Victoria (2005 -), E250 (2008-2009), E350 (2008-2009), E450 (2008-2009), Escape (2008-2012),

Explorer (2004), F150 (2006-2007) F250 (2006-2007), F350 (2006-2007), F450 (2006-2007),

F500 (2006-2007), F550 (2006-2008), Five Hundred (500)) Flex (2008-2012), Focus (2005-2008),

Freestar (2006 -), Freestyle (2005-), Merc Mariner (2008 -), Town car (2005-),Taurus (2008-2009, 2004)

2. IMMO Remote Control Programming:

Issued VW Touareg IMMO

Issued Audi A6/A7/A8 IMMO optimization

Issued Audi Q5/A4L generation 5

Optimize Ford Ranger, transit (Transit) IMMO programming (BUG:1337, BUG:1338)

Adding the IMMO system ISO type

3. Diagnostic Models:

Adding Renault new models:

ALASKAN\AVANTIME\CAPTUR/KAPTUR BR/IN/RU\CAPTUR/QM3/KABIN\CLIO II PH6\CLIO II\CLIO III\CLIO IV\CLIO V6 PH2\CLIO V6

CLIOIIP2/3/4\DOKKER/KANGOO\DUSTER PH2\DUSTER\ESPACE IV\ESPACE V\ESPACE\ESPACEIV PH2/3/4\KADJAR CN\KADJAR\KANGOO II,ect.

Adding Daxia new models:

1304_PK_1_POINT_9D\1304_DS_1_POINT_9D\1305_PK_1_POINT_9D\1305_DS_1_POINT_9D\D_POINT__CAB1_POINT_9D\SUPERNOVA

SOLENZA\LOGAN\SANDERO\DUSTER\LODGY\DOKKER,ect.

Adding Renault – Samsung new models:

CAPTUR_QM3_KABIN\CLIO_IV\KOLEOS_II_CN_QM6_CN\KOLEOS_II_QM6\KOLEOS_QM5\LATITUDE_SM5\MEGANE_IV_SEDAN\NEW_SM3_FLUENCE_MEGANE

SAFRANE2_Point_0_SM5_DF\SAFRANE_2_Point_3_SM7_LF\SCALA_SM3_CF,ect.

Adding Mercedes-Benz new models:

CLK-series\E/CLS-series\CLS-series\S/CL/Maybach- series\CL- series\SL/SLR/SLK- series\SLR- series\SLK- series\M/G/GL/GLK- Series\M-series\G-series

GL-series\R-series,ect.

Adding Maybach new models:

240.078 MAYBACH 57\240.079 MAYBACH 57S\240.077 MAYBACH 57 S\240.178 MAYBACH 62\240.179 MAYBACH 62S/R\240.177 MAYBACH 62 S,etc.

4. optimization

Optimize VW reset airbag

Optimize VW throttle

Optimize B30 VIN all 00 flashback (1334)

Optimize VW oilrvice reset

Optimize VW steering angle reset

Optimize VW EPB

Optimize VW battery matching

Optimization software (to solve the problem of DP device can not be tested)

First Issue FR language

Solve the error and content returns problem when diagnostic device enters the connection detection

Solve the multiple content coverage APP crash problem

Solve the APP crash problem during software update in Thai language

Solve the VCI.BIN failed to load when double click the diagnostic models list

Remove the password operation to clear fault code

PASU version adds ALTO 800 ID46 (Blank) IMMO system

Optimize Buick Royaum key programming

Optimize Chevrolet Koros

Optimize the Bluetooth communication of Audi Q7, A6L generation 4 (EEPROM backup)

Optimize NEC 24C64 read IMMO data algorithm

Optimize Transit IMMO system (BUG: 1302)

Solve the system entry failure of Corolla – 06 / 2004-> / Avensis – <- 04/2005 / LEXUS – Gs430

Optimized 510 smart key programming function security verification

Key Programming

Adding 310 Wagon smart key system function support

Added DX3 smart key programming function

Addingd Roewe ERX5, I6 smart key programming

Added Roewe 360 smart key programming

Added KWIND model key programming function

5. Injector Code

Adding injector code function new models

Audi

Automatic scanning

Manual selection
A1
A2
A3
A4
A5
A6
A7
A8
CABRIO
Q3
Q5
Q7
R8
RS3
RS5
S2
S3
S5
TT
TTRS
TTS
Chrysler
Automatic scanning
Manual selection
Cherokee (free light)
2014
2015
Ram 3500 Pickup
2011
2012
Ram 4500/5500
2011
2012
Town & Country
2011
300/Magnum/Charger
2006
2007
2008
2009
2010
Challenger
2008
2009
2010
Commander
2006
2007
2008
2009
2010
Grand Cherokee
2005
2006
2007
2008
2009
2010
Wrangler (Export)
2008
2009
2010

Solution about MB STAR C4, MB STAR C5 Update and can not test vehicles problems

Make sure your computer hardware version is higher the Car Diagnostic Scanners Tools mb star c4 or mb star c5 version, otherwise, CSD will show update failed . Bootimage can update successfully. The following picture show how to check the mb star c4 or mb star c5 version1
3-1
The following picture is show your computer hardware HDD software version66
3-2
If their software is not same, it no need update ( because factory has upgraded the latest version of the mb star c4 or mb star c5 machine)

If customer not use our HDD software, it will appear read vehicle failed problems.

Solution as following

(1) Mb star c4 or mb star c5 supply power to confirm the machine was turn on, like the following picture ( If now show the three icon, it means the mb star c4 or c5 main unit is broken)

3-3

(2). connect LAN with computer, confirm computer IP change to172.29.127.118, like the following picture :

3-4

(3)  change of software using pattern (Because you modify the software for the firmware upgrade mode, the software is not test the vehicles)The following picture is show the software is upgrade mode

3-5

The following picture is show test read vehicle mode.
3-6

Three files name Update_automaticx , Update_manualx ; Update_SpecialxThis is read vehicle mode, if can not read vehicle, please change files name, then restart computer

Autel MS908P “Authorization Check Failed Error Code:3″ Solutions

Autel MaxiSys Pro MS908P is the popular auto diagnostic tools which support ECU programming for BMW and mercedes online .
Rencently , the part of our customers gave us a feedback that they got an message as bellow picture showed :

Why did this happen ? Its because they have changed the language for the main unit , and then got this error .
So how to solve this issue ? Lets check the steps now
1. Connect to the internet
2. Log in PC Suit upgrade tool on networked computers
3. Obtain authorization automatically
If this serial number to determine the corresponding Autel ID, you can contact technical support queries.
Or if you have any other problems for autel products , you can contact with autel techinical service directly , please check the link here : http://support.autel.com/support/home
Thank you
