2017 new CGDI Prog MB is the fastest key programming tool to calculate Mercedes password and add key at present. Here is the user manual of CGDI MB key programmer.

Main Function:

1.Add a MB key or do all key lost: support models including 211,209,204,207,212,166,246,197,172,164+, 216

2. Fastest Benz Car key add: collection time 1’50s, password calculation time 40s, 99% get password for one time calculator

Workable Benz Car Model:
Mercedes-Benz A series (2004 -)
Mercedes-Benz B series (2005-)
Mercedes-Benz C Series (2001 – , including 210)
Mercedes-Benz E Series (2001-, including 203)
Mercedes-Benz CL series (2001-)
Mercedes-Benz GLK (2004-)
Mercedes-Benz ML series (2003 -)
Mercedes-Benz R series  (2003 -)
Mercedes-Benz G series (2003 -)
Mercedes-Benz S Series (2001 -, including 220)
Mercedes-Benz SLK  (2003- )
Mercedes-Benz SLS (2004 -)
Mercedes-Benz Vito (2003-)
Mercedes-Benz Sprinter (2003 -)
Mercedes-Benz Vito (2003 -)

EIS/EZS Function:
1). Can read EIS data via OBD, no need to distinguish the EIS/EZS model.
2). Can display the key status and directly disable the key position.
3). Can display EIS Number, can distinguish the Benz model
4). Can display EIS status.
5). Automatically identify EIS model.
6). Automatically identify CAN protocol

Programming Key Features:
1). Automatically identify the basic key information (including how many times you used SSID)
2). Can directly read pin code of BE keys via infrared, can erase BE keys.
3). NEC adapter can write the original Benz smart key and common key.
4). Can write the Benz original key via infrared.
5). Can restore the data of key and EIS with the key password.

Generate the Key Data:
1) Can generate the key data of HC05/908/912/9S12/NEC EIS/EZS
2) Time: 26 seconds
3) Format: 11/ 41/51 (41 format is smart key data)

Infrared Key Function:
1) Can directly read key pin code via infrared on parts of 209/211/220/215 EIS.
2)Can read/write EIS via infrared.

CGDI Prog MB Key Programmer User Manual

How to use CGDI Prog MB Key Programmer?

Lock (EIS)

Read EIS data

Calculate password

Copy key with key

Please insert key into EIS and click OK

Insert the key into the device and click OK

cgdi-prog-mb

Insert the original car key into the lock

Insert key into the device and wait for collection

Insert the car key into the lock for 10s and remove it

Insert the key into EIS

After 5s, insert the key into EIS

Insert the key into CGDI MB

Save the generated data

Save data

Upload data

Query Result

Query end

Calculate password word success. Copy the key pass

Paste the key password

Confirm key pass and Save EIS data

Save EIS data file successfully, click OK

Click Generate EE

Load EIS File

Generate Key File

M

Load EIS file and confirm key password

Save

Read/Write key

Click OK to confirm

Write BE key: select communication mode: Infrared

(NEC adapter: used for writing original  key, including smart key. Method: remove the chip to weld)

Read key/chip

Open/Write (insert the key into devices before click)

CGDI MB shows NEC adapter, ignore it

Smart key please choose 41 format, common key and BE key please choose 51 format.

select location to write key

Write key success

Password display area. Manually write down the password.

BE key read password directly, no need collect data.

CGDI Prog MB is possible to program Mercedes Benz W164 2009-/W221 2009- in 2 ways:  via OBD and on bench.

OBD mode takes about 2 hours.
Bench reading shorten the online calculation time to less than 4 minutes. (This requires CGDI MB AC adapter).

Here’s the how-to guide to program W221 all keys lost with CGDI MB on bench.

Step 1: Calculate Password
Open CGDI MB software

Go to Compute Password->Copy key without key->Collect data
Select collect data via Platform mode (quick collection)

Connect the AC Adapter with cgdi follow the wiring diagram
Insert the simulation key within 1 minute, if you have inserted, pull it out and try again

Turn the quick collect adapter switch to the Platform position
Turn ignition switch to ON position
Collection is done.Very fast.

Save file.

Save the file successfully. Upload the data to calculate password.

Upload data just saved

Press Query Result to calculate pass

CGDI MB calculates password success.
Copy the password

Step 2: Save new EIS data
Go to EIS->Read EIS data

Paste the password to corresponding area

Save EIS data

Step 3: Generate Key File

Select Generate Key File function

Select key file format and press Generate Key File

Save key file

Step 4: Write Key

Go to Read/Write Key->Read Key/Chip

Then Reset

Reset operation success

Read key again, check key information
Press Open/Write

Choose a key file (common BE key choose v51 format)
Write key success

How to: reset/renew Mercedes Benz W221 Continental DSM using CGDI Prog MB Key Programmer on bench.

Follow cgdi prog wiring diagram to connect DSM unit with CGDI MB

c

In CGDI MB software, select Auto Computer, Module type W221->ISM/DSM/ESM

Read DSM information

Press Get to calculate erase password

Erase password calculated successfully

Press Erase

Reset DSM success

Done.

How-to: repair Mercedes Benz W204, W207, W212 ELV using CGDI Prog MB Key Programmer.

Repair ELV with CGDI MB

Make good connection.

The CG-MB detects whether the EIS is normal. If normal, it can be repaired via OBD.

OBD connects with car, open CGDI software，click ‘Read ELV data ‘

please connect the clip on the yellow line of the OBD line to the k-line on the ELV plug.

Read data successfully, display related information

Check ELV is ok. Start repairing ELV

Get ELV erase password

Erase the ELV success

Read ELV data again, to display related information after erasing

Collect and calculate the anti-theft password

Read EIS Data

Enter ‘compute password’, select ‘copy key with key’（If lost all keys, you can choose ‘copy key without key

Default “other keys”, click OK

The collection process won’t be described one by one, just operate as the software instructed, eventually you
can obtain the anti-theft password

copy and paste the password to EIS

Save EIS data ( please default file name)

Get erase password successfully

Click ‘wipe the EIS，Suggest that insert the simulation key into the EIS in 30 seconds

Physical operation diagram

Erase the EIS success

CGDI MB Read EIS data again,display related information

Load original data（Previously saved EIS data）

Click ‘Write EIS data ‘

please insert the simulation key into the EIS in 30 seconds

Physical operation diagram

Write EIS data success

Read EIS data again, display related

cgdi-mb-repair-elv-25

click“sync w204 ELV”，prompt ‘sycn w204 ELV success, please insert key into EIS for activation

cgdi-mb-repair-elv-26

Activated successfully , ELV can be used normally.
